Fixed lights

Our fixed light, fire rated windows and screens that can be manufactured in a number of frame options to suit your particular design. The maximum dimensions for a single frame are 6m wide and 4m high and there are a number of coupling options so that long runs of frames can be designed. Finishes can be powder coated to any RAL colour or anodised

All frames can be glazed with glass units or insulated panels up to a thickness of 49mm. We are able to offer tinted and obscured glass options and we can incorporate coated glass products within double glazed units to achieve a large range of specific values which may be required for thermal insulation, light transmittance or solar gain requirements.

Doors

High specification single or double leaf doors are available to a maximum leaf size of 1400mm for single doors and 2500mm for double doors. The maximum door leaf height is 2500mm and fire rating up to EI90.

All doors are fitted with the Geze TS4000 overhead closer and Wala WX 3 way adjustable hinges, our standard locking arrangement comprises a single point dead latch with DDA approved lever handles which can be upgraded to include a multipoint lock and electric strike options.

We are also able to provide a single point or multipoint fire escape lock using either a lever handle or panic bar. Escape locking is very versatile and can be provided with a number of external access options.

Our fire rated door system can be supplied with a low threshold suitable for disabled access. For internal doors we can configure frames so that the door sits directly above your floor finish without the need for any type of threshold, this is particularly popular for internal partitions to offices or other public buildings.

In addition to manual swing doors we are can also offer an automatic sliding door system which will achieve a fire rating of EI30.

Wall partitions

Our wall partitions can achieve fire protection up to EI120. Configurations and size limitations are generally as our fixed lights with a maximum glass or panel thickness of 84mm. It is possible to incorporate our fire rated doors within this system, but the door can only be fire rated for a maximum of 90 minutes. There is also an option for glass to glass joints with this product, eliminating the requirement for thicker mullions in internal office or display screens.

Curtain Walling

Our fire rated curtain walling system is a specialist product (usually installed by OWS Ltd). The system is a quality mullion drained grid system and is enhanced with additional fire proof inserts, tapes, sealants and bracketry to be able to achieve a fire rating of up to EI60.

Glass and panel thicknesses of up 52mm can be incorporated and excellent thermal and acoustic values can be achieved. Maximum panel sizes of 3000mm wide x 1500mm high or 1200mm wide x 1800mm high can be included within the grid up to a maximum weight of 300kgs.

The system is visually compatible with our non-fire rated curtain walling and our door system can be fully integrated within the design.

Request a call back

Simply enter your name & number and one of our expert team members will call you back as soon as possible.

    Whether you have a new build or refurbishment project, discover how our industry leading products and services can deliver compliant performance for

    • compartmentation
    • boundary protection
    • protecting means of escape
